sensorProbe8-X20 - an intelligent sensor monitoring device for data centers and remote site locations
End of Life
We are sorry, but this product has been discontinued.

sensorProbe8-X20

High-Speed, Accurate and Rugged Remote Monitoring Device

At the core of the sensorProbe8-X20 is the sensorProbe8, which is then married with the 20 Dry Contact System. This offers support for remote monitoring and management of a wide range of external devices.

  • Product Code: SP8-X20

At the core of the sensorProbe8-X20 is the sensorProbe8, which is then married with the 20 Dry Contact System. This offers support for remote monitoring and management of a wide range of external devices.

The sensorProbe8-X20 system enables connection and monitoring of devices like HVAC Systems, Security Equipment, UPS, Generators, Industrial Equipment and much more.

The sensorProbe8-X20 embedded web server makes the addition of these devices easy. The sensorProbe8-X20 comes with 8 autoSense Intelligent sensor ports, for connecting a wide range of our intelligent sensors.

An additional 20x 2-wire dry contact ports are provided giving a total of up to 28 dry contact ports. The specially designed 2 wire dry contact ports are easy to use and allow you to make your own dry contact cables quickly. The sensorProbe8-X20 is a completely embedded host. It is equipped with a TCP/IP stack, internal web Server, e-mail and Full SNMP functionality.

sensorProbe8-X20 safeguards your infrastructure, resources and investment from external disaster before it happens.

Specifications

Dimension 44 (W) x 44 (H) low profile design

Mounting 1U Rack Mount Standard
Rack mount brackets included
Compatible with AKCP’s DIN and rack mount trays
Power External 5.5V 3A Power Adapter
Input Voltage and Current ratings : 100V~240V – 0.22A

Optional :
– PoE (PoE is IEEE 802.3af compliant)
– DCW (40-60V DC power input)

Power Consumption Typical : 1.90 Watt, 0.21A
Status Indication LED indication for power
LED for network connectivity
LED for sensor online and threshold status
LED for dry contact status
Components Manufactured using highly integrated, low power surface mount technology to ensure long term reliability.
Operating Environment Temperature : Min. -35° C – Max.80° C
Humidity: Min. 20% – Max. 80% (Non-Condensing)
MTBF 1,400,000 Hours based on field experience with sensorProbe units.
Inputs 8x Sensor Ports for connecting AKCP sensors*
20x 2 Wire dry contacts (Input only up to 5VDC and up to 40VDC in opto isolated mode using internal jumper setting)
1x 10/100 Mbps Ethernet Port
Outputs Configurable output signals (0VDC/5VDC) on any of the 8 RJ-45 sensor ports
  • Fully embedded TCP / IP and Web Server
  • Built-in notification Suite
  • 8 autoSense ports for AKCP sensors
  • Web-Based Interface for easy configuration and monitoring
  • Login for User and Administrator for increased security
  • Battery backed time of day clock for an accurate system date and time
  • A standalone product without any external hardware and software dependencies
  • Microcode firmware updates over the Internet
  • Customized color configuration for displaying alerts
  • Network Management System integration
  • An additional 20, 2 wire dry contact input ports are provided, giving a total of up to 28 dry contact ports
sensorProbe8-X20 rear panel diagram
