securityProbe5ESV-X60 - an intelligent sensor monitoring device for data centers and remote site locations

securityProbe 5ESV-X60

The only remote monitoring system you’ll ever need.

Monitor the physical environment and receive alerts of any disturbances, such as unauthorized intruders, security breaches, high temperatures, smoke, water leakages, power outages and more.

  • Product Code: SEC5ESV-X60

Monitor the physical environment and receive alerts of any disturbances, such as unauthorized intruders, security breaches, high temperatures, smoke, water leakages, power outages and more.

Compatible with the AKCP range of Intelligent Sensors, the SEC5ESV-X60 provides a complete environmental, access control and security solution for up to 500 connected sensors.

The securityProbe 5ESV-X60 has 60x 2 Wire Dry Contacts. An additional 2 Gigabyte SD card can be installed to provide greater storage capacity.

The SEC5ESV-X60 boasts High Speed USB 2.0 connectivity with ports available to connect up to 4x AKCP High Definition Digital Cameras and 1x EDGE-180M USB Modem.

Networked Monitoring

It is TCP / IP compliant and runs lighttpd web server including https (SSL), Bash, Perl, Telnet, PHP, Email and Nagios.

The SEC5ESV-X60 has an easy-to-use web-based user interface for sensor configuration, data collection and visual graphing. The SEC5ESV-X60 supports SNMP v3 with full encryption.

The securityProbe 5ESV-X60 also supports Modbus Master / Slave, Modbus RTU and Modbus over TCP / IP creating a unique, easy to configure Modbus to SNMP gateway.

The web-based interface is written in PHP allowing end-user changes such as language translation. The SEC5ESV-X60 has a battery time of day clock for accurate record keeping.



  • Size : 18” x 5” x 3.45”
  • Weight : 3.1 Kg

Expansion Ports

  • 2x individual RJ-45 expansion ports
  • Allows for quad directional
  • placement
  • 115.2K BPS data transfer rate
  • Simultaneous functionality between
  • Expansion ports & RS485 port
  • threshold status


  • 1U Rack mount brackets included

Power Requirements

  • Voltage 7.0 – 9 V / >= 3 Amp

Status Indication

  • LED indication for Power
  • LED for Network Connectivity
  • LED for sensor online and
    threshold status


  • Ext. Speaker Out, 3.5mm jack (Analog)
  • Mic Out, 3.5mm jack (Analog) for modem application


  • 8x RJ-45 ports for connecting AKCP sensors
  • 2x RJ-45 Expansion ports
  • 1x USB 2.0 Modem Port
  • 4x Video Ports
  • Audio In (Analog) 3.5mm jack
  • RS485, 2 pin Terminal box, (used for Modbus)
  • 60x Dry Contact Inputs

Operating Environment

  • Temp : Min. -35° C – Max. +55°C
  • Humidity : Min. 20% – Max. 80% (Non-Condensing)


  • Manufactured using highly integrated, low power surface mount technology to ensure long term reliability.
  • AKCP iMX25 Processor
  • 128 MB On-Board NAND Flash
  • HC SD Memory Slot on-board (up to 16GB

Power Consumption

  • Typical 6.150 Watt, 0.82A


  • 400,000 Hours

Expansion Modules

  • 8 Port Intelligent Sensors Module (E-sensor8)
  • 16 Port Dry Contacts Module (E-opto16)
  • Extendable up to 1,000 Feet or 300 meters
  • Expansion modules are daisy chainable
  • Embedded web server displays sensor information and live video from connected cameras
  • Control PTDZ cameras directly from the web interface
  • Record digital video to remote servers or internal memory, or send live images to your own website
  • Connect up to 2 High Definition Digital Cameras, and simultaneously display images up to 640×480 resolution
  • Receive notifications of anomalous events via email, SMS / MMS, SNMP traps, and many more
  • Integrates with network management systems via SNMPv1 and Encrypted SNMPv3
  • Stream video and sensor information directly to your cellphone or PDA
  • Ability to connect external GPRS / GSM modem, Bluetooth and WiFi USB adapters
  • Uses Linux operating system for maximum stability and flexibility
  • Virtual Sensors monitor power, Modbus, network devices, and other SNMP based equipment
  • Built-in graphing and data logging, internally or to a remote PC
  • Platform independent; free firmware upgrades and utilities from AKCP
  • Monitor up to 500 intelligent sensors using expansion modules ( E-Opto 16 and E-Sensor 8 )
  • Compatible with complete range of AKCP Intelligent Sensors
  • Full Modbus support : Modbus Master / Slave, Modbus RTU, Modbus over TCP / IP
securityProbe 5ESV-X60’s On Board Architecture

Up to 8 of AKCP’s Intelligent Sensors can be connected to the securityProbe 5ESV-X60. When plugged in, sensors automatically configure themselves and go ‘online’. Using the either the E-sensor8, or the E-opto16 expansion modules, up to 500 sensors can be connected to a single unit. Our easy-to-use port numbering system allows you to setup the securityProbe 5ESV-X60 within minutes.

  • AKCP iMX25 CPU
  • 128 MB of SDRAM
  • 128 MB On Board NAND Flash
  • 10/100 Mbps Ethernet Port
  • 1x USB 2.0 Modem Port
  • 4x Video Ports
  • 60x Dry Contact Inputs
  • RS485 Ports
  • Internal Audio Speaker
  • Internal Microphone
  • 8 Full AutoSense RJ-45 Ports (Maximum of 500 Sensors)
  • 4x RJ-45 Expansion Ports

PTDCConnect up to 4 External High Definition Digital Cameras
The securityProbe 5ESV-X60 can display pictures from a
maximum of four High Definition Digital Cameras simultaneously
in several sizes, up to 640×480 pixels resolution.

AKCP cameras are used in professional surveillance
and CCTV monitoring systems. A built-in pan-tilt
controller interface allows complete control of pan
and tilt cameras using the industry standard Pelco D bus.


USB Connectivity
Whether you are connecting the High Definition Digital Camera to a securityProbe 5ESV-X60 or a AKCP Door Control Unit. The connection type and port number is Universal.

Four video ports on the rear of each unit are assigned to High Definition Digital Camera connectivity.


Sensor Graphing
The securityProbe 5ESV-X60 integrates and displays graphs of all sensor data in its web-based user interface. The individual graph (day, week, month and year) for each sensor type can be customized, simply by modifying the script template used to generate a particular graph. RRD tool is used to build an embedded database of sensor data.

This data can be accessed from the web interface, or downloaded to a remote PC. MRTG can be used to generate real-time graphs of sensor data on a remote website.


Notifications & False Message Filter


Up to 8 of AKCP’s Intelligent Sensors can be connected to the securityProbe 5ESV-X60. When plugged in, the sensor automatically configures itself and goes online. Using the either the E-sensor 8, or the E-opto 16 expansion modules, up to 500 sensors can be connected to a single unit. Our easy-to-use web based interface allows you to setup the securityProbe 5ESV-X60 within minutes. When online, the sensors use their 4 levels of threshold checking and report any status change.

Notifications and alarms can be dependent on the states of multiple sensors, and can be configured to escalate in severity over time. The notification system can alert you of a problem via email, SMS messages and telephone calls, (additional hardware required), or send a message to any commercial network monitoring system using SNMP traps. The securityProbe 5ESV-X60 can automatically switch a relay on or off, wake-up or shutdown a remote server, send pictures and data via FTP, send a FAX, run your custom script and many more versatile functions.

The securityProbe 5ESV-X60 can automatically push out the complete status of the unit and sensors via the Heartbeat Message feature. This can be setup to be sent through e-mail, SMS or SNMP traps. A HTTP get script can also be chosen, allowing the data to be pushed to web servers.

False Message Filter

In order to prevent false alarms, the securityProbe 5ESV-X60 allows extensive filtering of events. You can limit events based on the time of day or the day of the week. You can also limit the number of alerts per hour, so that you are not swamped with many messages. This is especially important with the sensor like the motion detector where you may want to process an event only when the business premises are closed.


securityProbe5ESV-X60 Online Demo
We let you try before you buy!

Explore all the features of our best selling securityProbe5ESV-X60 over the internet using real, live data! No downloads or installations are required. Simply click on the ‘securityProbe5ESV-X60 Demo’ link below to gain quick and free access to AKCP’s securityProbe5ESV-X60.
